3M VHB 5930P Black Acrylic Foam Tape — 0.8mm Double-Sided Acrylic Foam Tape
Please select an option
| Material | Acrylic Foam |
|---|---|
| Roll weight | 3.684 kg |
| SKU | 5930P-133.35-33-76E3 |
| Ships from | Shenzhen, China |
3M VHB 5930P is a black, double-sided acrylic foam tape with a modified acrylic adhesive and a conformable closed-cell foam core, 0.8mm thick, supplied here as slit rolls, cut in-house to the widths and lengths shown on this page; other sizes can be cut on request. The tape is carried on a white polycoated kraft paper liner. It is used to bond nameplates, trim, electronic displays and panel-to-frame joints, including most powder-coated paints, and can replace rivets, welds and screws. It is not a gap-filling sealant: surfaces should be clean, dry and flat, and the joint should keep the tape in compression. Specifications: 3M VHB 5930P, black acrylic foam, total thickness 0.8mm (without liner); modified acrylic adhesive on a very conformable acrylic foam core; white polycoated kraft paper liner, which keeps its dimensions when the tape is kiss-cut. Temperature: up to 149 °C for short-term exposure (up to 4 hours) and up to 93 °C for long-term use. 3M supplies this product in standard widths from 12.7mm to 1168mm and roll lengths of 33m and above; the rolls listed here are slit and rewound in-house to the widths and lengths shown; other sizes can be cut on request.
References
- 3M™ VHB™ Tape 5930P — official 3M product page (specifications, thickness, colour, liner, temperature)
- 3M™ VHB™ Tape Design Guide — 3M official PDF (5930 / 5930P appear in the 5952 family table; states these tapes eliminate rivets, screws, bolts and welds)
- 3M™ VHB™ Acrylic Foam Tape 5930 family — 3M product data sheet (5930P belongs to this family)
Figures above are taken from 3M's own publications for the 5930 family (3M product page for 5930P and 3M product data sheet for the 5930 family). Test methods listed by 3M in those documents: peel adhesion ASTM D3330, total thickness ASTM D3652, foam density ASTM D3574, normal tensile ASTM D897, overlap shear ASTM D1002; UL 746C recognised. Published values for 5930P: 0.8mm total thickness (±15%), density 590kg/m³, short-term temperature up to 149 °C (up to 4 hours), long-term up to 93 °C, shelf life 24 months unopened at 4–38 °C.
Frequently asked questions
What sizes are available for 3M VHB 5930P Black Acrylic Foam Tape?
This product is in stock; the available sizes and roll lengths are listed in the specification table above and update as stock changes. Other widths and lengths can be converted to order — send us the dimensions you need.
How is shipping calculated?
Shipping is calculated by packed weight. Choose your country and enter a postal code in the cart, then select a service to see live UPS and FedEx rates; the amount carries into checkout.
Which countries do you ship to?
We currently ship to 40 countries and regions. Parcels are dispatched from Shenzhen, China; duties and taxes are paid by the recipient (DDU).
What is the return and exchange policy?
For consumables, report a quality issue with evidence within 14 days of receipt and we replace the product directly — no return needed. For bulk orders, email us to arrange a return.
Can this tape replace rivets, welds or screws?
Yes — 3M lists VHB 5930P as a replacement for mechanical fasteners such as rivets, welding and screws on painted and powder-coated surfaces. It is not a gap-filling sealant: surfaces should be clean, dry and flat, and the joint should keep the tape in compression. High heat, heavy static load or very rough surfaces still call for mechanical fastening.
How soon does the bond reach full strength?
This tape is pressure sensitive, so it bonds on contact and gives immediate handling strength. The values 3M publishes are measured at 22 °C after a 72-hour dwell time. Allow at least 72 hours after assembly before applying the design load; for low-temperature application, contact us to confirm.
